Life Safety (UL Rated)

UL-rated dampers for meeting fire and smoke safety requirements. This category includes fire dampers, smoke dampers, fire-smoke dampers, and ceiling radiation dampers.

Products

15D

1.5 Hour Rated Curtain Blade Dynamic Fire Damper

Featured

15DAH, 15DAV

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: A-Style
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15DB

1.5 Hour Rated Curtain Blade Dynamic Fire Damper

Featured

15DBH, 15DBV

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: B-Style
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15DC

1.5 Hour Rated Curtain Blade Dynamic Fire Damper

Featured

15DCH, 15DCV

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: C-Style
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

30D

3 Hour Rated Curtain Blade Dynamic Fire Damper

Featured

30DAH, 30DAV

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: A-Style
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

30DB

3 Hour Rated Curtain Blade Dynamic Fire Damper

Featured

30DBH, 30DBV

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: B-Style
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

30DC

3 Hour Rated Curtain Blade Dynamic Fire Damper

Featured

30DCH, 30DCV

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: C-Style
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

15DF

1.5 Hour Rated Dynamic Curtain Blade Thin Line Fire Damper

15DFV

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15DX

1.5 Hour Rated Curtain Blade Dynamic Fire Damper w/ Integrated Sleeve

15DXAH, 15DXAV

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: A-Style
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15DXB

1.5 Hour Rated Curtain Blade Dynamic Fire Damper w/ Integrated Sleeve

15DXBH, 15DXBV

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: B-Style
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15DXC

1.5 Hour Rated Curtain Blade Dynamic Fire Damper w/ Integrated Sleeve

15DXCH, 15DXCV

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: C-Style
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15MA

1.5 Hour Rated Non-Motorized Airfoil Blade Dynamic Fire Damper

15MAH, 15MAV, 15MACH, 15MACV

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15MD

1.5 Hour Rated Non-Motorized Single Thickness Blade Dynamic Fire Damper

15MDCH, 15MDCV

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15MD(SS)

1.5 Hour Rated Non-Motorized Stainless Steel Dynamic Fire Damper

15MDHSS, 15MDVSS

Maximum Velocity (FPM): 2000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15MD(SS) HP Series

1.5 Hour Rated Non-Motorized Stainless Steel Dynamic Fire Damper (HP Series)

15MDHSS4, 15MDVSS4

Maximum Velocity (FPM): 4000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

15MS

1½ Hr. Rated Vertical Mount Non-Motorized Fire Damper

15MSV

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Fire Resistance Rating (hrs): 1.5 hrs.

15S

1.5 Hour Rated Curtain Blade Static Fire Damper

15SAH, 15SAV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: A-Style
Fire Resistance Rating (hrs): 1.5 hrs.

15SB

1.5 Hour Rated Curtain Blade Static Fire Damper (B-Transition)

15SBH, 15SBV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: B-Style
Fire Resistance Rating (hrs): 1.5 hrs.

15SF

1.5 Hour Rated Curtain Blade Thin Line Static Fire Damper

15SFV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Style: A-Style

15SX

1.5 Hour Rated Curtain Blade Static Fire Damper w/ Integrated Sleeve

15SXAH, 15SXAV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: A-Style
Fire Resistance Rating (hrs): 1.5 hrs.

15SXB

1.5 Hour Rated Curtain Blade Static Fire Damper w/ Integrated Sleeve

15SXBH, 15SXBV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: B-Style
Fire Resistance Rating (hrs): 1.5 hrs.

15SXC

1.5 Hour Rated Curtain Blade Static Fire Damper w/ Integrated Sleeve

15SXCH, 15SXCV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: C-Style
Fire Resistance Rating (hrs): 1.5 hrs.

30DX

3 Hour Rated Curtain Blade Dynamic Fire Damper w/ Integrated Sleeve

30DXAH, 30DXAV

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: A-Style
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

30DXB

3 Hour Rated Curtain Blade Dynamic Fire Damper w/ Integrated Sleeve

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: B-Style
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

30DXC

3 Hour Rated Curtain Blade Dynamic Fire Damper w/ Integrated Sleeve

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: C-Style
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

30MA

3 Hour Rated Non-Motorized Airfoil Blade Dynamic Fire Damper

30MAH, 30MAV

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

30MA HP Series

3 Hour Rated Non-Motorized Airfoil Dynamic Fire Damper (4000 FPM, 4 in. w.g. Max)

30MAH4, 30MAV4

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

30MD

3 Hour Rated Non-Motorized Single Thickness Blade Dynamic Fire Damper

30MDH, 30MDV

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.

30S

3 Hour Rated Curtain Blade Static Fire Damper

30SAH, 30SAV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: A-Style
Fire Resistance Rating (hrs): 3 hrs.

30SB

3 Hour Rated Curtain Blade Static Fire Damper

30SBH, 30SBV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: B-Style
Fire Resistance Rating (hrs): 3 hrs.

30SC

3 Hour Rated Curtain Blade Static Fire Damper

30SCH, 30SCV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: C-Style
Fire Resistance Rating (hrs): 3 hrs.

30SX

3 Hour Rated Curtain Blade Static Fire Damper w/ Integrated Sleeve

30SXAH, 30SXAV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: A-Style
Fire Resistance Rating (hrs): 3 hrs.

30SXB

3 Hour Rated Curtain Blade Static Fire Damper w/ Integrated Sleeve

30SXBH, 30SXBV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: B-Style
Fire Resistance Rating (hrs): 3 hrs.

30SXC

3 Hour Rated Curtain Blade Static Fire Damper w/ Integrated Sleeve

30SXCH, 30SXCV

Material Options: Galvanized Steel
Blade Type: Curtain Blade
Frame Shape: Rectangular
Frame Style: C-Style
Fire Resistance Rating (hrs): 3 hrs.

CA1

Class I, 1.5 Hour Airfoil Blade Combination Fire-Smoke Damper

CA1H250, CA1H350, CA1V250, CA1V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA1 EP Series

Class I, 1.5 Hour Airfoil Blade Fire-Smoke Damper (3000 FPM, 4 in. w.g Max)

CA1H25034, CA1H35034, CA1V25034, CA1V35034

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA1 HE Series

Class I, 1.5 Hour Airfoil Blade Fire-Smoke Damper (4000 FPM, 6 in. w.g. Max)

CA1H25046, CA1H35046, CA1V25046, CA1V35046

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA1 HP Series

Class I, 1.5 Hour Airfoil Blade Fire-Smoke Damper (4000 FPM, 4 in. w.g. Max)

CA1H25044, CA1H35044, CA1V25044, CA1V35044

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA1GF ESB Series

Class I, 1.5 Hour Front Access Grille Airfoil Blade Fire-Smoke Damper (3.5-inch setback)

CA1HD250, CA1HD350, CA1VF250, CA1VF350

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA1GF SSB Series

Class I, 1.5 Hour Front Access Grille Airfoil Blade Fire-Smoke Damper (1.5-inch setback)

CA1HE250, CA1HE350, CA1VG250, CA1VG350

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA2

Class II, 1.5 Hour Airfoil Blade Combination Fire-Smoke Damper

CA2H250, CA2H350, CA2V250, CA2V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA2 EP Series

Class II, 1.5 Hour Airfoil Blade Fire-Smoke Damper (3000 FPM, 4 in. w.g. Max)

CA2H25034, CA2H35034, CA2V25034, CA2V35034

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA2 HE Series

Class II, 1.5 Hour Airfoil Blade Fire-Smoke Damper (4000 FPM, 6 in. w.g. Max)

CA2H25046, CA2H35046, CA2V25046, CA2V35046

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA2 HP Series

Class II, 1.5 Hour Airfoil Blade Fire-Smoke Damper (4000 FPM, 4 in. w.g. Max)

CA2H25044, CA2H35044, CA2V25044, CA2V35044

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA2GF ESB Series

Class II, 1.5 Hour Front Access Grille Airfoil Blade Fire-Smoke Damper (3.5-inch setback)

CA2HD250, CA2HD350, CA2VF250, CA2VF350

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA2GF SSB Series

Class II, 1.5 Hour Front Access Grille Airfoil Blade Fire-Smoke Damper (1.5-inch setback)

CA2HE250, CA2HE350, CA2VG250, CA2VG350

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CA2M

Class II, 1.5 Hour Modulating Airfoil Blade Combination Fire-Smoke Damper

CA2HM250, CA2HM350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F

CG1

Class I 1.5 Hour Single Thickness Blade Combination Fire-Smoke Damper

CG1H250, CG1H350, CG1V250, CG1V350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CG1(SS)

Class I 1.5 Hour Single Thickness Blade Stainless Steel Combination Fire-Smoke Damper

CG1H250SS, CG1H350SS, CG1V250SS, CG1V350SS

Maximum Velocity (FPM): 3000 fpm

Material Options: 304 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CG1GF ESB Series

Class I, 1.5 Hour Front Access Grille Fire-Smoke Damper (3.5-inch setback)

CG1HD250, CG1HD350, CG1VF250, CG1VF350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CG1GF SSB Series

Class I, 1.5 Hour Front Access Grille Fire-Smoke Damper (1.5-inch setback)

CG1HE250, CG1HE350, CG1VG250, CG1VG350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CG2

Class II 1.5 Hour Single Thickness Blade Combination Fire-Smoke Damper

CG2H250, CG2H350, CG2V250, CG2V350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CG2 ECF Series

Class II 1.5 Hour Tunnel-Type Combination Fire-Smoke Damper (3" Grille Clearance)

TG2C2I250, TG2C2K250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F

CG2(SS)

Class II 1.5 Hour Single Thickness Blade Stainless Steel Combination Fire-Smoke Damper

CG2H250SS, CG2H350SS, CG2V250SS, CG2V350SS

Maximum Velocity (FPM): 3000 fpm

Material Options: 304 Stainless Steel, or 316 Stainless Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CG2C

Class II 1.5 Hour Tunnel-Type Single Thickness Blade Combination Fire-Smoke Damper

TG2C250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F

CG2C GCF Series

Class II 1.5 Hour Tunnel-Type Fire-Smoke Damper (1.75" Grille Clearance)

TG2C2H250, TG2C2J250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F

CG2GF ESB Series

Class II, 1.5 Hour Front Access Grille Fire-Smoke Damper (3.5-inch setback)

CG2HD250, CG2HD350, CG2VF250, CG2VF350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CG2GF SSB Series

Class II, 1.5 Hour Front Access Grille Fire-Smoke Damper (1.5-inch setback)

CG2HE250, CG2HE350, CG2VG250, CG2VG350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CH1

Class I, 3 Hour Single Thickness Blade Combination Fire-Smoke Damper

CH1H250, CH1H350, CH1V250, CH1V350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CH2

Class II, 3 Hour Single Thickness Blade Combination Fire-Smoke Damper

CH2H250, CH2H350, CH2V250, CH2V350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CR1

Class I, 1.5 Hour Single Thickness Blade Mini Combination Fire-Smoke Damper

CR1H250, CR1H350, CR1V250, CR1V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CR2

Class II, 1.5 Hour Single Thickness Blade Mini Combination Fire-Smoke Damper

CR2H250, CR2H350, CR2V250, CR2V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CT1

Class I, 3 Hour Airfoil Blade Combination Fire-Smoke Damper

CT1H250, CT1H350, CT1V250, CT1V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CT1 EP Series

Class I, 3 Hour Airfoil Blade Fire-Smoke Damper (3000 FPM, 4 in. w.g. Max)

CT1H25034, CT1H35034, CT1V25034, CT1V35034

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CT1 HE Series

Class I, 3 Hour Airfoil Blade Fire-Smoke Damper (4000 FPM, 6 in. w.g. Max)

CT1H25046, CT1H35046, CT1V25046, CT1V35046

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CT1 HP Series

Class I, 3 Hour Airfoil Blade Fire-Smoke Damper (4000 FPM, 4 in. w.g. Max)

CT1H25044, CT1H35044, CT1V25044, CT1V35044

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CT2

Class II, 3 Hour Airfoil Blade Combination Fire-Smoke Damper

CT2H250, CT2H350, CT2V250, CT2V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CT2 EP Series

Class II, 3 Hour Airfoil Blade Fire-Smoke Damper (3000 FPM, 4 in. w.g. Max)

CT2H25034, CT2H35034, CT2V25034, CT2V35034

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CT2 HE Series

Class II, 3 Hour Airfoil Blade Fire-Smoke Damper (4000 FPM, 6 in. w.g. Max)

CT2H25046, CT2H35046, CT2V25046, CT2V35046

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CT2 HP Series

Class II, 3 Hour Airfoil Blade Fire-Smoke Damper (4000 FPM, 4 in. w.g. Max)

CT2H25044, CT2H35044, CT2V25044, CT2V35044

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F to 350 °F

CT2M

Class II, 3 Hour Modulating Airfoil Blade Combination Fire-Smoke Damper

CT2HM250, CT2VM250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 3 hrs.
Temperature Rating (°F): 250 °F

GA1

Class I Airfoil Blade Smoke Damper

GA1H250, GA1H350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

GA1 EP Series

Class I Airfoil Blade Smoke Damper (EP Series)

GA1H25034, GA1H35034

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

GA1 HE Series

Class I Airfoil Blade Smoke Damper (HE Series)

GA1H25046, GA1H35046

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

GA1 HP Series

Class I Airfoil Blade Smoke Damper (HP Series)

GA1H25044, GA1H35044

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

GA2

Class II Airfoil Blade Smoke Damper

GA2H250, GA2H350, GA2V250, GA2V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

GA2 EP Series

Class II Airfoil Blade Smoke Damper (EP Series)

GA2H25034, GA2H35034

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

GA2 HE Series

Class II Airfoil Blade Smoke Damper (HE Series)

GA2H25046, GA2H35046

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

GA2 HP Series

Class II Airfoil Blade Smoke Damper (HP Series)

GA2H25044, GA2H35044

Maximum Velocity (FPM): 4000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

GA2M

Class II Airfoil Blade Modulating Smoke Damper

GA2HM250, GA2VM250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F

R5

1½ Hour Rated True Round Single Blade Fire Damper

R5

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: True Round Single Thickness (UVU)
Frame Shape: Round
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

RC4

Insulated Dual Opening Static Ceiling Radiation Damper

RC4

Material Options: Galvanized Steel
Frame Shape: Rectangular
Insulation: Insulated (unspecified)

RCI

Insulated Static Rectangular Ceiling Radiation Damper

RCI

Material Options: Galvanized Steel
Frame Shape: Rectangular
Insulation: Insulated (unspecified)

RCU

Uninsulated Static Rectangular Ceiling Radiation Damper

RCU

Material Options: Galvanized Steel
Frame Shape: Rectangular
Insulation: Uninsulated

RDI

Insulated Static Round Ceiling Radiation Damper

RDI

Material Options: Galvanized Steel
Frame Shape: Round
Insulation: Insulated (unspecified)

RDU

Uninsulated Static Round Ceiling Radiation Damper

RDU

Material Options: Galvanized Steel
Frame Shape: Round
Insulation: Uninsulated

RG

Class I True Round Combination Fire-Smoke Damper

RG250, RG350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: True Round Straight
Frame Shape: Round
Pressure Drop: .015 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F to 350 °F

RT

Class I True Round Smoke Damper

RT250, RT350

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: True Round Straight
Frame Shape: Round
Pressure Drop: .02 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

S3

1½ Hour Rated True Round "Philips" Curtain Fire Damper

S3

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: True Round Curtain
Frame Shape: Round
Maximum Velocity (FPM): 3000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.

SG1

Class I Single Thickness Blade Smoke Damper

SG1250, SG1350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

SG1(SS)

Class I Single Thickness Blade Stainless Steel Smoke Damper

SG1250SS

Maximum Velocity (FPM): 3000 fpm

Material Options: 304 Stainless Steel
Blade Type: Single Thickness Blade
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F

SG2

Class II Single Thickness Blade Smoke Damper

SG2250, SG2350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

SG2 EP Series

Class II Single Thickness Blade Smoke Damper (3000 FPM, 4 in. w.g. Max)

SG225034

Maximum Velocity (FPM): 3000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F

SG2(SS)

Class II Single Thickness Blade Stainless Steel Smoke Damper

SG2250SS

Maximum Velocity (FPM): 3000 fpm

Material Options: 304 Stainless Steel
Blade Type: Single Thickness Blade
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 3000 fpm (FPM)
Temperature Rating (°F): 250 °F

SR1

Class I Single Thickness Blade Smoke Damper w/ Integrated Sleeve

SR1H250, SR1H350, SR1V250, SR1V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

SR2

Class II Single Thickness Blade Smoke Damper w/ Integrated Sleeve

SR2H250, SR2H350, SR2V250, SR2V350

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .03 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Temperature Rating (°F): 250 °F to 350 °F

TG2C DAN Variant

Class II 1.5 Hour Tunnel-Type Single Thickness Blade Fire-Smoke Damper (No Flange)

TG2C2G250

Maximum Velocity (FPM): 2000 fpm

Material Options: Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel
Frame Shape: Rectangular
Pressure Drop: .06 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2000 fpm (FPM)
Fire Resistance Rating (hrs): 1.5 hrs.
Temperature Rating (°F): 250 °F
