Industrial Dampers

Control and balancing dampers for industrial HVAC. Designed and built for heavy-duty applications.

Products

C545INS

10" Deep Industrial Insulated Airfoil Control Damper (Clean Air)

C545INS

Maximum Velocity (FPM): 8000 fpm
Max Static Pressure: 10 .in w.g. @ 1000 fpm
Pressure Drop: .1 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel / Opposed
Pressure Drop: .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 8000 fpm (FPM)
Temperature Rating (°F): 200 °F

PC30

4" Deep Light Industrial Airfoil Control Damper

PC30

Maximum Velocity (FPM): 4000 fpm
Max Static Pressure: 4 .in w.g. @ 1000 fpm
Pressure Drop: .035 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel / Opposed
Frame Shape: Rectangular
Pressure Drop: .035 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Temperature Rating (°F): 250 °F

PC33

8" Deep Light Industrial Single Thickness Control Damper

PC33

Maximum Velocity (FPM): 4000 fpm
Max Static Pressure: 5 .in w.g. @ 1000 fpm
Pressure Drop: .017 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Frame Shape: Rectangular
Pressure Drop: .017 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Temperature Rating (°F): 250 °F

PC34

8" Deep Light Duty Industrial Galvanized Damper

PC34

Maximum Velocity (FPM): 4000 fpm
Max Static Pressure: 10 .in w.g. @ 1000 fpm
Pressure Drop: .017 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Frame Shape: Rectangular
Pressure Drop: .017 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 4000 fpm (FPM)
Temperature Rating (°F): 250 °F

PC41

10" Deep Industrial Single Thickness Blade Control Damper

Maximum Velocity (FPM): 2500 fpm
Max Static Pressure: 6 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2500 fpm (FPM)
Temperature Rating (°F): 250 °F

PC42

10" Deep Industrial Single Thickness Blade Control Damper

PC42

Maximum Velocity (FPM): 2500 fpm
Max Static Pressure: 8 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2500 fpm (FPM)
Temperature Rating (°F): 250 °F

PC43

10" Deep Formed Steel Industrial Control Damper

PC43

Maximum Velocity (FPM): 2500 fpm
Max Static Pressure: 10 .in w.g. @ 1000 fpm
Pressure Drop: .05 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Single Thickness Blade
Blade Action: Parallel / Opposed
Frame Shape: Rectangular
Pressure Drop: .05 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 2500 fpm (FPM)
Temperature Rating (°F): 250 °F

PC50

10" Deep Industrial Formed Steel Airfoil Control Damper

PC50

Maximum Velocity (FPM): 8000 fpm
Max Static Pressure: 12 .in w.g. @ 1000 fpm
Pressure Drop: < .1 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel / Opposed
Frame Shape: Rectangular
Pressure Drop: < .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 8000 fpm (FPM)
Temperature Rating (°F): 450 °F

PC51

10" Deep Industrial Formed Steel Airfoil Control Damper

PC51

Maximum Velocity (FPM): 8000 fpm
Max Static Pressure: 20 .in w.g. @ 1000 fpm
Pressure Drop: < .1 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel / Opposed
Pressure Drop: < .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 8000 fpm (FPM)
Temperature Rating (°F): 450 °F

PC54

10" Deep Industrial Formed Steel Airfoil "Hi-Temp" Control Damper

PC54

Maximum Velocity (FPM): 8000 fpm
Max Static Pressure: 15 .in w.g. @ 1000 fpm
Pressure Drop: < .1 in. w.g. @ 1000 fpm

Material Options: Hot Rolled Steel
Blade Type: Airfoil Blade
Blade Action: Parallel / Opposed
Pressure Drop: < .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 8000 fpm (FPM)
Temperature Rating (°F): 800 °F

PC55

10" Deep Industrial Formed Steel Airfoil Control Damper (Clean Air)

PC55

Maximum Velocity (FPM): 8000 fpm
Max Static Pressure: 10 .in w.g. @ 1000 fpm
Pressure Drop: < .1 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Galvanized Steel
Blade Type: Airfoil Blade
Blade Action: Parallel / Opposed
Pressure Drop: < .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 8000 fpm (FPM)
Temperature Rating (°F): 400 °F

PC80

Industrial Single Blade Round Control Damper

PC80

Maximum Velocity (FPM): 10000 fpm
Max Static Pressure: 12 .in w.g. @ 1000 fpm
Pressure Drop: < .1 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Fabricated Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: < .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 10000 fpm (FPM)
Temperature Rating (°F): 250 °F

PC81

Industrial Heavy Duty Round Control Damper

PC81

Maximum Velocity (FPM): 10000 fpm
Max Static Pressure: 16 .in w.g. @ 1000 fpm
Pressure Drop: < .1 in. w.g. @ 1000 fpm

Material Options: 304 Stainless Steel, 316 Stainless Steel, or Fabricated Steel
Blade Type: Single Thickness Blade
Blade Action: Single
Frame Shape: Round
Pressure Drop: < .1 in. w.g. @ 1000 fpm
Maximum Velocity (FPM): 10000 fpm (FPM)
Temperature Rating (°F): 250 °F
